Product short description:
  • Intel® Tiger Lake-H Xeon-W CPU
  • SOSA-aligned
  • XMC slot
  • 100GbE
  • 32GB DDR4 RAM
  • Air/Conduction-Cooled

The VPX7600 is an I/O Intensive single board computer featuring an Intel 11th Generation Xeon W-11000E Series processor. It was developed in alignment with the Sensor Open Systems Architecture (SOSA) Technical Standard.

The high-performance 8-core processor supports up to 32GB of dual-channel, soldered-down DDR4 ECC memory with data rates of up to 3200 MT/s. An integrated Intel Gen12 UHD graphics Xe 32EU engine supports clock speeds of up to 1.35 GHz. Data storage, up to 1TB, is handled by an NVMe M.2 BGA SSD.

VPX7600: 3U VPX Single Board Computer Description

The VPX7600 is an I/O Intensive single board computer featuring an Intel 11th Generation Xeon W-11000E Series processor. It was developed in alignment with the Sensor Open Systems Architecture (SOSA) Technical Standard.

The high-performance 8-core processor supports up to 32GB of dual-channel, soldered-down DDR4 ECC memory with data rates of up to 3200 MT/s. An integrated Intel Gen12 UHD graphics Xe 32EU engine supports clock speeds of up to 1.35 GHz. Data storage, up to 1TB, is handled by an NVMe M.2 BGA SSD.

A wide variety of I/O peripherals are supported, plus an XMC expansion site enables advanced computation capabilities with plug-in mezzanine modules. The Intel E810 Ethernet controller provides 100GbE and 10GbE ports.

Other backplane peripheral interfaces offer great flexibility. A 2.5-gigabit Ethernet port supports Time Sensitive Networking (TSN). DisplayPort 1.4 enables HBR3 data rates and 4K resolution. USB 3.2 and USB 2.0 offer versatile, high-speed interfaces for many uses, while a SATA III port simplifies data storage connections. Additional interfaces include RS232, RS422, and discrete GPIO lines.

Board support packages facilitate use with Microsoft Windows®, Linux®, and VxWorks™ operating systems.

Acromag has more than 60 years of experience working with defense, aerospace, scientific, and industrial applications. We are committed to providing embedded computing solutions with the best long-term value in the industry. These boards are designed and manufactured in the USA for the highest quality, security, and reliability.

Learn more about Acromag’s VPX SBC and see all VPX models.

VPX7600: 3U VPX Single Board Computer Features & Benefits

  • Intel® Tiger Lake-H Xeon-W CPU
  • SOSA-aligned I/O Intensive SBC profile
  • Intel 11th Gen Xeon-W Tiger Lake-H 8-Core CPU
  • 32GB of dual channel DDR4 SDRAM with ECC
  • Up to 1TB (64GB standard) of NVMe SSD on-board storage
  • 100G Ethernet Data Plane
  • x4 PCIe Gen3 Expansion Plane
  • 10G Ethernet Control Plane
  • IPMC System Management
    • HOST 3.0
    • VITA 46.11 Tier-3
  • XMC Expansion Site
  • Backplane I/O includes:
    • 1x 2.5GBASE-T/1GBASE-T Ethernet port
    • 1x DisplayPort 1.4 interface
    • 1x USB 3.2 port
    • 1x USB 2.0 port
    • 1x SATA III port
    • 4 x GPIO
    • 1x RS-422 (or 2x RS-232) ports

Learn more about Acromag’s VPX SBC and see all VPX models.

Additional information

Weight 16 oz
Dimensions 7 × 4 × 1 in
Part Number

VPX7600-42-20: 3U VPX SBC, air-cooled with front I/O, VPX7600-42-50: 3U VPX SBC, conduction-cooled

Product Series

AcroExpress
